Targus USB-C Universal DV4K 100W Docking Station DOCK182EUZ
The Targus DOCK182EUZ USB-C Universal DV4K Docking Station transforms a compatible laptop into a powerful multi-display workstation with dual 4K UHD display support, extensive USB connectivity, Gigabit Ethernet and up to 100W USB-C Power Delivery. Equipped with two HDMI 2.0 and two DisplayPort 1.2a outputs, the dock can drive up to two 4K displays at 60Hz while a combination of USB-A and USB-C ports provides high-speed connectivity for storage, keyboards, mice and other peripherals.
Key Features
Dual 4K UHD display support: Connect up to two external monitors at resolutions up to 4K UHD 60Hz for an expanded desktop workspace.
HDMI and DisplayPort connectivity: Features 2 × HDMI 2.0 and 2 × DisplayPort 1.2a outputs, allowing flexible dual-display configurations.
Up to 100W Power Delivery: USB Power Delivery 3.0 can charge and power compatible USB-C laptops with up to 100W through the host connection.
High-speed USB connectivity: Four USB-A 3.2 Gen 1 ports provide up to 5Gbps transfers, while a USB-C 3.2 Gen 2 port supports speeds up to 10Gbps.
Gigabit Ethernet: Integrated RJ45 networking provides a reliable wired Gigabit Ethernet connection.
3.5mm combination audio: Connect compatible headphones or headsets for calls, conferencing, entertainment and other audio applications.
Broad host compatibility: Designed for USB-C and USB-A host systems and compatible with Windows, macOS, Android, Chrome OS and Ubuntu Linux.
VESA mounting provision: Can be mounted behind a compatible display using the separately sold Targus ACX003GLZ VESA Mounting Bracket.
Dual 4K UHD Workstation
Expand a laptop workspace across up to two external displays with resolutions up to 4K UHD at 60Hz. Two HDMI 2.0 and two DisplayPort 1.2a outputs provide flexibility when connecting compatible monitors, allowing dual-display configurations using HDMI, DisplayPort or a combination of both connection types.
100W USB-C Power Delivery
Power Delivery 3.0 provides up to 100W of power to compatible USB-C laptops, allowing the dock to handle charging, displays, networking and peripherals through a single host connection. The included 150W AC power adapter supplies power to the docking station, eliminating the need to use a separate USB-C laptop charger for supported systems.
High-Speed Peripheral Connectivity
Four USB-A 3.2 Gen 1 ports provide data transfer rates of up to 5Gbps for keyboards, mice, storage devices and other USB peripherals, with one port supporting fast charging. A USB-C 3.2 Gen 2 port provides transfer speeds of up to 10Gbps for compatible high-speed USB-C devices.
Universal Host Compatibility
The DOCK182EUZ supports compatible USB-C and USB-A host computers and is Thunderbolt 3 compatible. Targus supplies a detachable 1-metre USB-C host cable with a tethered USB-A adapter, providing additional flexibility when connecting different laptop types. Supported operating-system families include Windows, macOS, Android, Chrome OS and Ubuntu Linux.
Technical Specifications
Specification
Details
Brand
Targus
Model
DOCK182EUZ
Manufacturer Part Number
DOCK182EUZ
Product Type
Universal USB-C Docking Station
Connection Technology
USB 3.2 Gen 2
Host Compatibility
USB-C and USB-A; DisplayPort Alt Mode; Thunderbolt 3 compatible
Maximum External Displays
2
Maximum Display Resolution
Up to 4K UHD at 60Hz
HDMI Ports
2 × HDMI 2.0
DisplayPort
2 × DisplayPort 1.2a
USB-A Ports
4 × USB-A 3.2 Gen 1
USB-A Data Rate
Up to 5Gbps
Fast-Charging USB-A Ports
1
USB-C Peripheral Ports
1 × USB-C 3.2 Gen 2
USB-C Peripheral Data Rate
Up to 10Gbps
Ethernet
1 × RJ45 Gigabit Ethernet
Audio
1 × 3.5mm combination audio port
USB Power Delivery
Power Delivery 3.0
Maximum Host Power
Up to 100W
Power Delivery Output Voltages
5V, 9V, 12V, 15V, 20V
Power Source
Wall power
AC Power Adapter
150W; 19V / 7.89A output
Host Cable
1m detachable USB-C to USB-C cable
USB-A Host Adapter
Included; tethered to host cable
Supported Operating Systems
Windows, macOS, Android, Chrome OS, Ubuntu Linux
VESA Mounting Provision
Yes; compatible with Targus ACX003GLZ bracket, sold separately
Security Lock Slot
Kensington T-bar compatible
Colour
Black
Dimensions (W × H × D)
17.9 × 3.2 × 8.3 cm
Weight
0.35 kg
EAN
5051794035940
Manufacturer Warranty
3-year limited warranty
What’s in the Box:
1 × Targus USB-C Universal DV4K Docking Station with 100W Power Delivery (DOCK182EUZ)
1 × 1m USB-C to USB-C Host Cable with Tethered USB-A Adapter
1 × 150W AC Power Adapter
1 × 1.8m AC Power Cord with UK/European Plugs
1 × Quick Start Guide
Build a flexible professional workstation with dual 4K 60Hz display support, up to 100W laptop charging, HDMI and DisplayPort connectivity, high-speed USB, Gigabit Ethernet and broad host compatibility using the Targus DOCK182EUZ Universal DV4K Docking Station.
